2022 Adventure Neo 4

Introduction

Every day is an Adventure.

Anelectric-bikebuilt for the city streets, the town pathways,and the great openroads. You arejustone ride away from a good mood.

Where it thrives

City streets, village lanes, beautiful backroads

What it’s built for

Getting around, going to work, enjoying the day

Highlights

• Lightweight aluminum step-thru frame
• Shimano Altus 9-speed shifting / hydraulic disc brakes
• Bosch Active Line 250W drive-unit / 400Wh battery / Range: up to up to 65 mi

Specs

Details

• PlatformAdventure Neo
• Model NameAdventure Neo 4
• Model CodeC68401U

Frameset

• FrameSmartForm C3 Alloy step-thru frame, removable downtube battery, fully internal cable routing, post mount disc, dual water bottle headtube mount
• ForkSmartForm C3 Alloy blades, 1-1/8″ steerer, post mount disc, mid-blade rack/fender mounts, crown accessory mount, 45mm offset
• HeadsetSemi-Integrated, 1-1/8″

E-System

• Drive UnitBosch Active Line
• BatteryBosch PowerTube 400Wh
• ChargerBosch 2A
• DisplayBosch Purion

Drivetrain

• Rear DerailleurmicroSHIFT Marvo, 9-speed
• ShiftersmicroSHIFT Marvo XPress M859, trigger style, 9-speed
• ChainKMC Z9, 9-speed
• CrankFSA Bosch E-Bike, 38T
• Rear CogsmicroSHIFT, 11-36, 9-speed

Brakes

• BrakesTektro M275 hydraulic disc, 180/160mm rotors
• Brake LeversTektro hydraulic disc

Wheels

• RimsCannondale 2, double wall
• SpokesStainless Steel, 14g
• TiresKenda Kwick Seven.5, 27.5 x 2.20″
• Tire Size56
• Wheel Size650b
• Hubs(F) Formula DC-1420, QR / (R) Formula DC-1422, QR
• Front TireKenda Kwick Seven.5, 27.5 x 2.20″
• Rear TireKenda Kwick Seven.5, 27.5 x 2.20″

Components

• HandlebarCannondale E-Series Alloy, ergo backsweep, 680mm
• StemCannondale 3 with Intellimount, Alloy, 31.8mm clamp
• GripsCannondale Comfort
• SaddleCannondale Ergo Comfort
• SeatpostCannondale 4, 6061 Alloy, 31.6 x 350mm

Connectivity

• Wheel SensorCannondale Wheel Sensor
